Thomas & Betts Thomas & Betts OB-22
Thomas & Betts OB-22
Kirby Risk #: 2169916
UPC: 78378674050, 78502314472, 785023144725, 40783786740503
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Thomas & Betts
Description
Industry Description
Aluminum H-Type Compression Connectors, length 1-1/2 inch, die O..325-.162 inch on one side, .325-.162 on the other side
Modified Industry Description
ALUMINUM H TYPE COMPRESSION CONNECTOR, 1 1/2 IN LONG
AD Description
Blackburn® OB-22 Compression H-Tap Connector, H, 6 to 2 AWG Main/Run, 6 to 2 AWG Tap, Aluminum
Specifications
| Application |
Used to Dead End Aluminum, ACSR or Aluminum Alloy Conductors.
|
|---|---|
| Brand Name |
Thomas & Betts
|
| Conductor Type |
ACSR/Solid/Stranded
|
| Connection |
Crimp
|
| Conductor Size |
6
|
| Country of Origin |
MX
|
| Finish |
Bare
|
| Insulation |
None
|
| Material |
Aluminum
|
| Mounting |
None
|
| Package_Quantity |
1
|
| Size |
Length 1-1/2 inches
|
| Special Features |
|
| Standard |
RUS Accepted. Complies with ANSI C119.4 Specifications
|
| Sub_Brand |
Blackburn
|
| Tap_Size |
6 to 2
|
| Temperature_Rating |
90
|
| Type |
H-Tap
|
| Voltage Rating |
None since Uninsulated
|
