Siemens Siemens 3NE1818-0
Siemens 3NE1818-0
Kirby Risk #: 2161044
UPC: 75455493006, 754554930060, 4011209132382, 00662643084467, 00754554930060
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Siemens
Description
Industry Description
FUSE,63A,AC,690VGR.000 63A , AC 690 V ,(SIZE 000) UTILIZ. CATEGORY GR, DIN 43620 SITOR FUSE-LINK
Modified Industry Description
FUSE,63A,AC,690VGR.000
AD Description
Sentron™ 3NE1818-0 Fuse Link, 690 VAC, 63 A, For Use With SITOR Semiconductor Fuse System
Vendor Description
SITOR semiconductor fuses in LV HRC design can also be used, although it must be noted that, compared to cable and line protection fuses, these get much hotter during operation. For this reason, the fuse must be operated below the rated current In of the device (derating) when installed in a closed switching device.
Specifications
| Amperage Rating |
63
|
|---|---|
| Application |
SUPPLEMENTARY PROTECTION
|
| Class |
GS
|
| Connection |
N/A
|
| Country of Origin |
DE
|
| Dimensions |
79.9 mm L x 53.3 mm W x 21 mm D
|
| Frequency_Rating |
N/A
|
| Interrupt_Rating |
100kA
|
| Length1 |
3.4000
|
| Material |
N/A
|
| Mounting |
On standard mounting rail (DIN 35mm)
|
| Mounting_Type |
DIN Rail
|
| Size |
NH000
|
| Special Features |
|
| Standard |
GOST, CCC, UL
|
| Sub_Brand |
Siemens
|
| Temperature_Rating |
-20 to 50
|
| Type |
Semiconductor Fuses SITOR
|
| Voltage Rating |
690
|
