Fluke FLUKE 77-4


Description

Industry Description

The Fluke 77-IV digital multimeter has the features needed to repair most electrical and electronic problems. This meter is simple to use and has significant improvements over Fluke's original 70 Series with more measurement functions, conformance to the latest safety standards, and a much larger display that's easier to view.

Modified Industry Description

10A 1000V DC/AC 50 MOhm Digital Multimeter

Specifications

Accuracy
+/- (2% + 2) for AC Voltage, +/- (0.3% + 1) for DC Voltage
Amperage Rating
60 mA to 10 A
Application
Take measurements to repair most electrical and electronic problems
Battery
9 V Alkaline, NEDA 1604 / 1604A
Battery_Type
9 VDC Alkaline, NEDA 1604/1604A V
Brand Name
FLUKE
Capacitance
1 nF to 9999 uF
Country of Origin
UKN
Dimensions
7.28 in H x 3.54 in W x 1.7 in D
DimensionsInches
7.28 x 3.54 x 1.7
Diode_Test
True
Display
Digital: 6000 counts, updates 4/sec; Bar graph: 33 segments, updates 32/sec; Frequency: 10,000 counts; Capacitance: 1,000 counts
Enclosure
Hard Plastic
Frequency_Rating
99.99 Hz to 99.99 kHz
Material
Plastic
Measuring_Range
1000 VDC/VAC, 10 A, 50 MOhm
Model
Fluke 77 IV
Package_Quantity
5
Resistance
600 Ohm to 50 MOhm
Safety_Rating
CAT III 1000 V, CAT IV 600 V
Special Features

  • 400 hr typical alkaline
  • ANSI/ISA S82.02.01, CSA C22.21010.1, IEC 61010 to 1000 VAC measurement category III, 600 VAC measurement category IV
  • Auto and manual ranging
  • Backlight for work in dim areas
  • Capacitance range 1 nF, 10 uF, 100 uF with accuracy of +/-(1.2% + 2), 9999 uF with accuracy of 10%
  • Digital 6000 count, update 4/sec, bar graph 33 segments display
  • Ergonomic over-molded housing with integrated probe holders
  • Free your hands with the optional TPAK magnetic hanger
  • Frequency range 99.99 Hz, 999.9 Hz, 9.999 kHz, 99.99 kHz with accuracy of +/-(0.1% + 1)
  • Large display that makes easier to view
  • Min/max to record signal fluctuations
  • Resistance range - 600 Ohm, 6 kOhm, 60 kOhm, 600 kOhm, 6 MOhm, 50 MOhm with accuracy of +/-(0.5% + 1)
Standard
Safety: ANSI/ISA S82.02.01, CSA C22.2-1010.1, IEC 61010 to 1000 V Measurement Category III, 600 V Measurement Category IV; Certifications: CSA, TÜV (EN61010), ?, (N10140)
Sub_Brand
Fluke
Temperature_Rating
-10 to 50
Type
Digital
Voltage Rating
600 mVAC to 1000 VAC, 6 to 1000 VDC
