SolaHD SolaHD ES5H15S
SolaHD ES5H15S
Kirby Risk #: 2102633
UPC: 78347200020, 783472000203, 00783472000203
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: SolaHD
Description
Industry Description
Features:Wall Mounting Bracket (WB1C), Primary Amperage 62.5/31.3A, Secondary Amperage 125/62.5A, 220 DEG C Insulation System, Standard:UL, KVA Rating:15KVA, Primary Voltage:240/480V AC, Secondary Voltage:120/240V AC
Modified Industry Description
15 KVA 240 X 480 V PRIMARY 120/240 SECONDAY 1 PHASE WALL MOUNT TRANSFORMER
AD Description
SolaHD ES5H15S Ventilated Distribution Transformer With WS-10 Optional Weather Shield, 240/480 VAC Primary, 208/120 VAC Secondary, 15 kVA, 60 Hz, 1 Phase
Specifications
| Brand Name |
SolaHD
|
|---|---|
| Country of Origin |
US
|
| Enclosure |
NEMA 1
|
| Frequency_Rating |
60
|
| Insulation |
220
|
| KVA_Rating |
15
|
| Maximum_Amperage_Rating |
62.5/31.3/125
|
| Mounting |
Wall
|
| Number_Of_Taps |
2
|
| Phase |
1
|
| Power_Rating |
15
|
| Primary_Voltage |
240/480
|
| Secondary_Voltage |
120/240
|
| Special Features |
|
| Standard |
UL 1561
|
| Sub_Brand |
SolaHD
|
| Type |
Ventilated
|
| Winding |
Copper
|
