Federal Signal Federal Signal USIX-120TC


Description

Industry Description

Hazardous Location UniStat Status Indicator 120VAC Tri-Color (Amber, Green and Red) - Available in 24VDC and 120VAC. Tri or quad-color models. 50,000 hour, vibration-resistant LED light source. Surface mount. PLC compatible. UL and cUL Listed for Class I, Division 2, Groups A, B, C, D, Class II, Division 2, Groups F and G, and Class III. Type 4X, IP66, IP69K enclosure.

Modified Industry Description

UniStat™, tri-color, hazardous

AD Description

Federal Signal UniStat™ USIX-120TC Status Indicator Stack Light, 120 VAC, LED Lamp, 1 Light, Clear, 50000 hr

Vendor Description

The unistat is a led (light emitting diode) based, multi-color, single high status indicator. Using the latest led technology, this unique status indicator can produce three colors (amber, green and red) or four colors (amber, blue, green and red) from a single light source. The unistat offers a choice of four integrated flash patterns steady burn, slow flash, strobe flash and SimuStrobe™. SimuStrobe™ simulates the attention getting flash rate of a strobe light but with a much more color rich output. The user can choose a total of 12 possible flash/color combinations in the tri-color models and 16 in the quad color models.

Specifications

Amperage Rating
0.058
Application
Indoor
Average_Life
50000
Brand Name
Federal Signal
Cable_Entry
3/4" NPT
Color
Clear
Country of Origin
US
Dimensions
11.07 in H x 4.75 in W x 4.75 in D
Enclosure
Type 4X, IP66
Environmental_Conditions
-40 to 150
Label_Description
NULL
Lamp_Type
LED
Lens_Color
Clear
Lens_Material
Polycarbonate
Material
Polycarbonate
Mounting
Surface Mount
NEMA_Rating
NEMA 4X/IP66
Size
11.07H X 4.75 Diameter
Special Features

  • Four integrated flash patterns
  • PLC compatible
  • Vibration-resistant LED light source
Standard
UL and cUL Listed
Sub_Brand
Federal Signal
Type
Hazardous Location Status Indicator
Voltage Rating
120
