O-Z/Gedney O-Z/Gedney LB6X200MA


Description

Industry Description

OZ-Gedney Type LB Mogul Conduit Body, 2 IN Hub, Length: 14.63 IN, 3.13 IN Width, 6.31 IN Height, Copper-Free Aluminum, Finish: Epoxy Powder Coat, Connection: Tapered FNPT, 145 CU-IN Volume, Third Party Certification: UL File Number E-18095, CSA 009795, Applicable Third Party Standards: UL 514A, CSA C22.2 No.18, Federal Specification Number A-A-50563, Hazardous Locations: Class 1, Division 2 Per NEC Section 501-4(B), NEMA : FB-1, FB-2.10, For Rigid Conduit And IMC

Modified Industry Description

2 IN LB MOGUL COND BDY ALUM

Specifications

Application
For Rigid Conduit And IMC
Connection
Tapered FNPT
Country of Origin
MX
Dimensions
14.63 in L x 3.13 in W x 6.31 in H
Enclosure
NEMA FB-1/FB-2.10
Finish
Epoxy Powder Coated
Length1
14.7000
Material
Copper Free Aluminum
Mounting_Type
Surface
Special Features

  • Accurately tapped, tapered threads for tight, rigid joints and excellent ground continuity
  • Form 85™ copper free aluminum UNILETS™ are lightweight, self oxidizing, self-renewing and offer a high corrosion resistance
  • Lightweight aluminum facilitates shipping, handling and installing
  • Roomy interiors more wiring space
  • Sizes with flat back design ideal where fitting is mounted flat against surface
  • Smooth, rounded integral bushing in hubs protects conductor insulation
Standard
Third Party Certification: UL File Number E-18095, CSA 009795, Applicable Third Party Standards: UL 514A, CSA C22.2 No.18, Federal Specification Number A-A-50563, Hazardous Locations: Class 1, Division 2 Per NEC Section 501-4(B), NEMA : FB-1, FB-2.10
Type
Type LB Mogul
