Siemens Siemens CMD63B700H
Siemens CMD63B700H
Kirby Risk #: 2024053
UPC: 78364321515, 783643215153, 00783643215153
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Siemens
Description
Industry Description
SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. ASSEMBLED 100 PERCENT RATED STANDARD 40 DEG C BREAKER MD FRAME WITH FUSELESS CURRENT LIMITING BREAKING CAPACITY. 700A 3-POLE (65KAIC AT 600V) (100KAIC AT 480V). NON-INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES NO LUGS INSTALLED. DIMENSIONS (W x H x D) IN 9.00 x 16.0 x 6.00.
AD Description
Sentron™ CMD63B700H Molded Case Circuit Breaker, 600 VAC/500 VDC, 700 A, 65 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Vendor Description
Siemens Sentron™ series circuit breakers have a long history of excellent performance in both the commercial and industrial market segments, they are tried and true in the most critical applications. Siemens Sentron™ series circuit breakers are available in nine frame sizes from 125 A to 2000 A.
Specifications
| Actuator |
Varying
|
|---|---|
| Amperage Rating |
700
|
| Application |
Standard 40C Breaker
|
| Connection |
N/A
|
| Country of Origin |
MX
|
| Dimensions |
16 in L x 9 in W x 10 in H
|
| Enclosure |
Varying
|
| Environmental_Conditions |
N/A
|
| Frame |
MD
|
| Frequency_Rating |
50/60
|
| Interrupt_Rating |
65
|
| Length1 |
10.0000
|
| Material |
N/A
|
| Number_Of_Poles |
3
|
| Operating_Temperature |
40C
|
| Phase |
3-Phase
|
| Special Features |
|
| Standard |
UL/HACR/100% Rated
|
| Sub_Brand |
SENTRON
|
| Temperature_Rating |
40
|
| Type |
CMD6
|
| Voltage Rating |
600 VAC/500 VDC
|
