Crouse-Hinds Crouse-Hinds DSD919


Description

Industry Description

DSD COVER AND DEVICE SUB ASSEMBLIES

Modified Industry Description

DSD COVER HAZ LOC -SUB ASSEMBLY-

AD Description

Crouse-Hinds DSD919 Factory Sealed Heavy Duty Pushbutton Control Station With Internal Brake Chopper Circuit, 600 VAC, 2NO-2NC Contact, NEMA 3/7B/7C/7D/9E/9F/9G NEMA Rating

Specifications

Amperage Rating
10
Application
EDSCM Modular Control Device Bodies and EDS/EDSC Back Boxes
Color
Black
Country of Origin
MX
Enclosure
Class I Div 1 2 Group B C D, Class II Div 1 Group E F G, Class II Div 2 Group F G, Class III, NEMA 3/7B/7C/7D/9E/9F/9G
Finish
Natural
Length1
6.6000
Material
Copper Free Aluminum
NEMA_Rating
NEMA 3/7B/7C/7D/9E/9F/9G
Series
DSD
Special Features

  • 1-cover button
  • 2-circuit universal
  • Accurately ground flange for flame tight joint when mated with ground flange on back box
  • Dust-ignition proof, explosion proof, rain tight
  • For covers with front lever and side rocker type operating handles, threaded type shafts and bushings are used to ensure flame tightness
  • Large machine screws for fastening covers to bodies
  • Lockout hole for padlock having 1/4 in hasp is provided when used with covers for front lever and side rocker type operation
  • Lockout provisions on front operated pushbutton (marked "STOP" and "OFF") and all selector switch covers
  • Used on EDS/EFS series back box
Standard
UL 894, 698, CSA C22.2
Sub_Brand
Eaton Crouse-Hinds
Type
Factory Sealed Heavy Duty
Voltage Rating
600
