Panduit Panduit LCAX750-58-3

Name: Panduit LCAX750-58-3
Brand: Panduit
SKU: 1930656
Price: 98.94 USD
Availability: InStock

Panduit LCAX750-58-3

Kirby Risk #: 1930656

UPC: 07498343610, 074983436101, 00074983436101, 30074983436102

Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)

Brand: Panduit

Description

Industry Description

One-hole, flex lug, 750 kcmil cable, 5/8 stud hole.

Modified Industry Description

COPPER COMPRESSION LUG, 1 HOLE,

AD Description

Panduit® Pan-Lug™ LCAX750-58-3 1-Hole Compression Lug, 777.7 kcmil DLO Copper Conductor, Die Code: P115, 5/8 in Stud, Tin Plated Copper

Brand Name	Panduit
Color	Yellow
Conductor Material	Copper
Conductor Size	777.7 kcmil DLO
Country of Origin	MEX
Material	Tin Plated Copper
Mounting	1 3/4
Number_Of_Holes	1
Package_Quantity	1
Size	777.7 kcmil DLO
Special Features	Can be used with code conductor and flex conductor class G, H, I, K, M and diesel Locomotive Color-coded bands for proper die selection and crimp placement Generously beveled wire entry prevents bent back strands when inserting conductor into barrel Inspection window to assure complete conductor insertion Tin-plated to inhibit corrosion
Standard	C22.2 No. 65-13, 486A-486B File #E52164, ABS approved
Stud_Size	5/8
Sub_Brand	Panduit
Temperature_Rating	90
Type	1-Hole
Voltage Rating	35
