3M 3M MNHU18-250DMIX
3M MNHU18-250DMIX
Kirby Risk #: 1907765
UPC: 00051128589175, 051128589175, 05112858917
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: 3M
Description
Industry Description
3M™ Scotchlok™ Color-Coded Heat Shrink Male Disconnect Terminal allows for quick and easy disconnect. The butted-seam barrel is covered by an adhesive-lined polyolefin tubing to offer moisture-seal protection. It withstands a maximum temperature of 221 degrees F (105 degrees C). Its electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.
Modified Industry Description
Fully Nylon Insulated Butted Seam
AD Description
Scotchlok™ MNHU18-250DMIX Disconnect Tab, 22 to 18 AWG Conductor, 1/4 in Tab, Butted Barrel, ETP Copper, Red
Vendor Description
Heat shrink pre-insulated adhesive terminals, connectors and disconnects protect against the most challenging of environments, making the best moisture protection available. They offer several advantages over conventional unsealed products.
Specifications
| Brand Name |
3M
|
|---|---|
| Color |
Red
|
| Conductor Size |
22 to 18 AWG
|
| Country of Origin |
US
|
| Label_Description |
MALE DISCONNECT HEATSHRINK NYLON INSULATED, 25/BOTTLE
|
| Material |
ETP Copper
|
| Operating_Voltage |
25 per bottle
|
| Package_Quantity |
25
|
| Special Features |
|
| Sub_Brand |
3M
|
| Tab_Size |
1/4 in
|
| Terminal_Size |
22 - 18 AWG
|
| Type |
Disconnect
|
