O-Z/Gedney O-Z/Gedney B300


Description

Industry Description

OZ-Gedney Type B Insulated Bushing, Size: 3 IN, Malleable Iron, Finish: Zinc Plated, Connection: Threaded, 150 DEG C, 4 IN Outside Diameter, 1 IN Width, Third Party Certification: UL File Number E-11853, CSA 011584, Applicable Third Party Standards:

Modified Industry Description

3 IN INSUL BSHG

Specifications

Application
For Threaded Rigid Conduit And IMC
Connection
Threaded
Country of Origin
MX
Dimensions
4 in OD x 1 in W
Finish
Zinc Plated
Length1
7.7000
Material
Malleable Iron
Size
3
Special Features

  • Molded on high impact phenolic thermosetting insulation
  • O-Z/Gedney specification grade insulated bushings help protect insulated conductors from abrasion during pulling or due to mechanical vibration
  • Positive metallic conduit stop
  • They also provide a voltage gradient between the live conductors and ground at the point where conductor insulation is subjected to electrical and mechanical stress
  • Type B insulated bushings of malleable iron or steel, with conduit end stop and integrally molded noncombustible phenolic insulated surfaces rated 150 deg C shall be used on the ends of all raceways containing number 4 or larger conductors
Standard
Third Party Certification: UL File Number E-11853, CSA 011584, Applicable Third Party Standards: UL 514B, CSA C22.2 No.18, Federal Specification W-F-408E, NEMA : FB-1
Temperature_Rating
302
Type
Type B
