Thomas & Betts Thomas & Betts IKL56


Description

Industry Description

Aluminum 4 inch Service Entrance Compression Splice for Wire Range - Black End: 3/0 ASCR, 3/0 STR, 4/0 CPT, 3/0 CPR. Yellow End: 1/0 ASCR, 1/0 STR, 2/0 CPT, 1/0 CPR. Installing Dies: TX 249 840 (EEI 11A). Compound and Capped. includes 5-7/16 inch Sleeve

Modified Industry Description

INSUL.SERVICE ENTRY SLEEVE

AD Description

Blackburn® IKL56 Insulated Service Entrance Splice, 1/0 to 4/0 AWG ACSR/Compact/Stranded Conductor, Die Code: 840, 5-1/2 in L, Aluminum

Vendor Description

Blackburn® stands for quality and reliability as a supplier of materials to connect overhead distribution power lines and equipment.

Specifications

Application
For Heavy-Duty Overhead Services
Brand Name
Thomas & Betts
Color
Yellow
Conductor Range
Wire Range - End A: 3/0 ASCR, 3/0 Stranded, 4/0 Stranded, Compact, Yellow, End B: 1/0 ASCR, 1/0 Stranded, 2/0 Stranded, Compact, Yellow
Connection
Crimp/ Compression
Conductor Size
1/0 to 4/0
Country of Origin
US
Environmental_Conditions
All Seasons / Conditions
Insulation
True
Material
Aluminum
Mounting
None
Special Features

  • 3/0 AWG ACSR, 3/0 AWG stranded, 4/0 AWG stranded compact end A and 1/0 AWG ACSR, 1/0 AWG stranded, 2/0 AWG stranded compact end B conductor
  • 840 die series, B49EA, 840 U-K840, U-249 hydraulic dies, BY37, 840 W-K840 and TX mechanical dies
  • All seasons environmental conditions
  • Color coded and marked for easy identification
  • Concave polyethylene end caps seal out dirt, but are easily pierced when inserting conductor
  • For heavy duty overhead services
  • Pre-insulated for fast, easy installation of large home or commercial service entrances
  • Prevents oxidation and keeps out moisture
  • Provides high conductivity
  • Resist installing tool pressure and provide reliable 600 VAC insulation
  • Use as a low tension reducing sleeve for insulated conductor
Standard
RUS Listed. Passes the Requirements of ANSI C119.4
Sub_Brand
Blackburn
Type
Insulated
Width_2
9.6250
