Allen-Bradley Allen-Bradley 802T-HTP
Allen-Bradley 802T-HTP
Kirby Risk #: 12935
UPC: 00662468079846, 662468079846, 10662468079843, 66246807984
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Allen-Bradley
Description
Industry Description
Plug-In Oiltight Limit Switch,Metal,10 A Standard Energy,Rotary Lever Arm,4 Circuits,Conduit Entry,Standard Contacts,2 Normally Open Contacts,2 Normally Closed Contacts,Standard Low Temprature, -18°C,110 °C High Temp Limit,Snap Acting,1/2" NPT Thread,Clockwise & Counter Clockwise,Low Angle Op.9°, Spring Return,Full Switch (Head & Body),NEMA Style Standard Mounting,Not Direct Acting,802T Plug-in Style,7 lb in,9 Degree Angle,3.5 Degree Angle,A300,154
Modified Industry Description
4PST - STD ENERGY - CW AND CCW OP - HIGH OP TORQUE - METAL PLUG-IN OILTIGHT LIMIT SWITCH
Specifications
| Action |
Snap Acting,Standard Contacts
|
|---|---|
| Actuator |
Rotary Lever Arm
|
| Application |
Full Switch (Head & Body)
|
| Brand Name |
Allen-Bradley
|
| Connection |
Cable Length Not Applicable,Number of Pins Not Applicable,Conduit Entry,Connector Type Not Applicable
|
| Contact_Configuration |
4 Circuits
|
| Contact_Rating |
A300
|
| Country of Origin |
DO
|
| Enclosure |
Metal
|
| Mounting |
NEMA Style Standard Mounting
|
| Number_Of_Poles |
4
|
| Operating_Temperature |
110 °C High Temp Limit,Standard Low Temprature, -18°C
|
| Package_Quantity |
1
|
| Size |
802T Plug-in Style
|
| Special Features |
Indicator Config - Not Appli
|
| Standard |
CCC, CE, CSA, KC, UL
|
| Sub_Brand |
Allen-Bradley
|
| Type |
Plug-In Oiltight Limit Switch
|
| Voltage Rating |
10 A Standard Energy
|
